9
EUROPOWER PMX2000
6. SPECIFICATIONS
6. SPECIFICATIONS
Mono inputs
Microphone inputs
Type XLR, electronically balanced,
discrete input circuit
Mic E.I.N. (20 Hz - 20 kHz)
@ 0 Ω source resistance -122 dB / 125 dB A-weighted
@ 50 Ω source resistance -122 dB / 125 dB A-weighted
@ 150 Ω source resistance -121 dB / 124 dB A-weighted
Frequency response <10 Hz - 100 kHz (-1 dB),
<10 Hz - >200 kHz (-3 dB)
Gain +33 dB, +8 dB with pad
Max. input level +12 dBu @ +8 dB gain
Impedance approx. 2.2 k Ω balanced /
1.1 k Ω unbalanced
Signal-to-noise ratio 110 dB / 114 dB A-weighted
(-11 dBu In @ +33 dB gain)
Distortion (THD+N) 0.001% / 0.0008% A-weighted
Mono line inputs
Type 1/4" TRS connector, balanced
Impedance approx. 80 k Ω balanced,
40 k Ω unbalanced
Max. input level 30 dBu
Stereo line inputs
Type 1/4" TRS connector, unbalanced
Impedance approx. 40 k Ω unbalanced
Max. input level +28 dBu
EQ
Low 60 Hz / ±15 dB
Mid 700 Hz / ±15 dB
High 6 kHz / ±15 dB
Preamp outputs left/mono & right
Type 1/4" TRS connector, unbalanced
Impedance approx. 1.5 k Ω
Max. output level +21 dBu
Power amp inputs
Type 1/4" TRS connector, unbalanced
Impedance approx. 47 k Ω
Max. input level +21 dBu
Monitor output
Type 1/4" TRS connector, unbalanced
Impedance 1.5 k Ω
Max. output level +21 dBu
DSP 24-bit Texas Instruments TM
Converter 24-bit Sigma-Delta,
64/128-times oversampling
Sampling rate 46.875 kHz
Main mix system data 1
Noise
Main mix @ -oo,
Channel fader -oo -76 dB / -80 dB A-weighted
Main mix @ 0 dB,
Channel fader -oo -72 dB / -76 dB A-weighted
Main Mix @ 0 dB,
Channel fader @ 0 dB -71 dB / -75 dB A-weighted
Power amp specifications
Power amp output
Stereo mode 250 Watts into 4 Ω
180 Watts into 8 Ω
“Bridge” mode 500 Watts into 8 Ω
Loudspeaker connections
Loudspeaker connector NEUTRIK NL4MP SPEAKON ®
connector
Load impedance
Left/monitor 4/8/16 Ω
Right/mono main 4/8/16 Ω
Bridge 8/16 Ω
Power supply
Mains voltages U.S./Canada 120 V ~, 60 Hz
U.K./Australia 240 V ~, 50 Hz
Europe 230 V ~, 50 Hz
General export model 100 - 120 V ~, 200 - 240 V ~, 50 - 60 Hz
Power consumption max. 1 kW
Fuse 100 - 120 V ~: T 10 A H
200 - 240 V ~: T 6.3 A H
Mains connection Standard IEC receptacle
Physical/weight
Dimensions (H x W x D) approx. 11" (280 mm) x 18 1/8"
(460 mm) x 10 5/8" (270 mm)
Weight (net) approx. 15 kg (33 lbs)
Measuring conditions:
1: 20 Hz - 20kHz; measured at preamp output.
All channels: level controls in center position; EQ flat.
Reference = 0 dBu.
BEHRINGER is constantly striving to manintain the highest professional standards. As a
result of these efforts, modifications may be made from time to time to existing products without
prior notice. Specifications and appearance may differ from those listed or illustrated.
