Table of burner and nozzle specifications
Table 1
Liquid Gas
Natural Gas
Diameter
(mm)
Thermal Power
kW (p.c.s.*)
By Pass
1/100
Nozzle
1/100
Flow*
g/h
Nozzle
1/100
Flow*
l/h
Nozzle
1/100
Flow*
l/h
Burner
Nominal Reduced
(mm)
(mm)
***
**
(mm)
(mm)
Fast
(Large)(R)
100
3.00
0.7
41
87
218
214
128
286
143
286
Semi Fast
(Medium)(S)
75
1.90
0.4
30
70
138
136
104
181
118
181
Auxiliary
(Small)(A)
51
1.00
0.4
30
52
73
71
76
95
80
95
Supply
Pressures
Nominal (mbar)
Minimum (mbar)
Maximum (mbar)
28-30
20
35
37
25
45
20
17
25
13
6,5
18
*
At 15°C 1013 mbar-dry gas
***
Butane P.C.S. = 49,47 MJ/Kg
**
Propane P.C.S. = 50,37 MJ/Kg
Natural P.C.S. = 37,78 MJ/m³
S S
R
A
C 34S N1 R /HA
