At start up the display readout shows the set DMX Adress: e.g. A 1
SOFTWARE MANUAL
SW3
AREA 48 SOFT
WWW.BROTHERS-SONS.DK
Software vers. 1_4_00
DMX Operation:
When a DMX cable is connected and is transmitting DMX signal from a DMX controller,
the unit will indicate that that DMX is being received by turning on the DMX present indicator in the display.
If a unit is started up without DMX present it will start up in manual mode, but will switch to DMX
mode as soon as a DMX signal is detected.
The unit will stay in DMX mode even if DMX signal is lost. The behavior of the the unit in case of the signal
loss can be set in the menu under Mode - noDMX see below.
Note: Beware, when using Strobe Lenght, that if the Strobe Lenght is egual to or longer than
the flash and interval between flashes, the unit will not strobe.
If maximum strobe length is used the fastest strobe possible will be 17 ( 7% )
DMX Channels
Mode Channel Parameter Value Percent Function
8 Bit 1 Dimmer 0 - 255 0 - 100 Coarse dimming
8 Bit 1 Dimmer 0 - 255 0 - 100 Coarse Dimming
w. Strobe 2 Strobe 0 - 5 0 Open
mode 6 - 125 1 - 49 Slow to Fast Strobe
126 - 130 50 Open
131 - 250 51 - 99 Slow to Fast Random
251 - 255 100 Open
3 Strobe 0 0 - 100 Short to Long Flash
length
16 Bit 1 Dimmer 0 - 255 0 - 100 Coarse dimming
2 Dimmer 0 - 255 0 - 100 Fine dimming
16 Bit 1 Dimmer 0 - 255 0 - 100 Coarse dimming
w. Strobe 2 Dimmer 0 - 255 0 - 100 Fine dimming
3 Strobe 0 - 5 0 Open
mode 6 - 125 1 - 49 Slow to Fast Strobe
126 - 130 50 Open
131 - 250 51 - 99 Slow to Fast Random
251 - 255 100 Open
3 Strobe 0 0 - 100 Short to Long Flash
length
