At start up the display readout shows the set DMX Adress: e.g. A 1 (Adress 1)
DMX Operation:
If DMX signal is received a dot in the display above the DOWN button will light up.
If a unit is started up without DMX present it will start up in manual mode, but will switch to DMX
mode as soon as a DMX signal is detected.The unit will stay in DMX mode even if DMX signal is lost.
The behavior of the the unit in case of the signal loss can be set in the menu under Mode - noDMX.
8 bit: Channel 1: Dimmer
if strobe is enabled: Channel 2: Strobe mode
Channel 3: Strobe length
16 bit: Channel 1+2: Dimmer
if strobe is enabled: Channel 3: Strobe mode
Channel 4: Strobe length
DMX Channels
Software update
When updating the software any adress or user specified settings are not affected by the update.
Battery power operation
Not all batteries V lock or Bauer can handle the powerdraw on 100 %
The unit is consuming up to 125 watts on batteries.
If you experience that the unit switches off after a couple of seconds and reboots it may be for 2 reasons
A.The battery is close to empty - B.The Battery cannot handle the load
We have made the following function to avoid the situation where the unit is set to 100 %
and you cannot change it because the battery switches off before you can set it to a lower %
Disconnect the battery, reconnect the battery and within the first 5 seconds press and hold ENTER
until the display reads: MAN 00 Now select a level your batteries can handle using UP and DOWN buttons
Area 48 on web
- accessories
- manuals
- software
BBS YouTube channel
- Video guides
- Video reviews
BBS FACEBOOK
Manual operation (No DMX connected)
When the Area 48 Soft is switched on the display will show the light level e.g. “ 0”
Use the UP and DOWN buttons to set the desired light level.
The level will be autosaved after 10 seconds, indicated by display readout “SAVED” or can be saved instantly
by pressing ENTER after setting the light level. After saving a light level the ENTER button can be used to
toggle between 0 and the saved level. The display reads out “MANUAL” for 0 and a number for the stored
intensity level. If power is lost, the unit will, when power is restored, automatically go to the saved light level
after 5 seconds. If a DMX signal is connected when in Manual mode, the unit will switch to DMX mode.
To reenter Manual mode; remove DMX signal and switch unit off and then back on OR navigate to MANUAL in
the menu.
QUICK START
AREA 48
Software vers. 2_0_05
