SOFTWARE MANUAL
SW4
AREA 48 SOFT
WWW.BROTHERS-SONS.DK
Software vers. 2_0_05
Addr 1 DMX adress value 1 - 512
M
ode Resolution 8 bit resolution
16 bit resolution (default)
Response Slow (fade between values) (default)
Fast (snap between values)
Curve Square dimmer curve (default)
Linear dimmer curve
Strobe OFF (default)
On - (adds 2 strobe channels)
noDMX Action when loss of DMX signal:
HOLD - last received DMX value (default)
OFF - Sets output to zero
MAN - Go to Manual DMX value
Display OFF 2n - Display off after 2 minutes (default)
ON - Display always on
Tools Ver Shows software version - READOUT ONLY
HW Ver Shows hardware version - READOUT ONLY
L Temp LED temperature - READOUT ONLY
P Temp PCB temperature - READOUT ONLY
DMX In 3 first digits shows DMX adress - READOUT ONLY
3 last digits shows DMX value - READOUT ONLY
Using up and down dmx value for all channels can be viewed.
Reset Confirm (Reset unit by pressing enter)
test display Display test - all seven segments of each digit on - READOUT ONLY
Log Log C° Minimum and maximum logged LED temperature in °C
UP and DOWN scrolls min. and max.
MaxPCB Maximum logged PCB temperature in °C
on time PSU on time in hours - READOUT ONLY
on LED LED on time in hours - READOUT ONLY
on Cnt Counts number of times unit has been switched on.
Serial Internal serial number used as service number.
Demo Demo of 1 min. fade 0 - 100 % - repeatedly.
PSU U PSU voltage in Volts - READOUT ONLY
DMX HZ DMX refresh rate - READOUT ONLY
DMX CH No. of DMX ch. transmitted by controller. - READOUT ONLY
DMX br Break lenght of DMX in microseconds - READOUT ONLY
Manual 0 Manual intensity 0 - 100%
Intensity saved when pressing ENTER
(Display is always on in manual mode)
MENU TREE
