Manual 2100-467
Page 14 of 23
HEAT ON UNITS WITH 15 OR MORE KW
W
MIS-2149
D1 DH W3
OR
E2
Unit 24V
Block
Y C G R Y1 B W1 W2 L E
Y1 C G R W1 B Y2
R
Terminal
W2
W3
P
L D E
E L W2 B W1 R G C
A1
Unit Control Panel
G Y
Y
T8400C1313
Thermostat Subbase
IF93-380
OR
T8511G1070
REMOVE JUMPER FOR 2 STAGE ELECTRIC
FIGURE 6
LOW VOLTAGE WIRING
