Manual 2100-467
Page 11 of 23
FIGURE 4
ELEVATED MOUNTING PLATFORM
48" min.
32°F or lower climate
12" min. if in
on surface of platform
Both legs must rest
48" min.
32°F or lower climate
12" min. if in
on surface of platform
Both legs must rest
Metal frame
MIS-2144
Platform can be as
shown or solid
Poured concrete,
brick, or block
* AS REQUIRED
*
*
