MVBELTS
Single supply belt mount system for
V-lock type battery packs
The user is being alerted of the importance of going through the literature
accompanying this product and familiarising oneself with the important safety and
operating instructions included.
Introduction:
The BLUESHAPE MVBELTS system is designed to provide cameramen with a handy power source
for their equipment. The unit operates with any V-lock type battery. The unit simply transports the
mounted battery's output voltage to the 4 pin XLR and at the same time, to the D-tap connector.
The unit is not internally fused so the user has to be careful and use only professionally made
connections.
This unit is intended for snapping on a waist belt by means of its large stainless steel suspension
spring.
The maximum recommended continuous current should not exceed 5A.
Main features:
Small light-weight V-Mount system that can be suspended to any waist belt (not provided)
Easy to insert and remove
Allows the installation of a single battery of type BV070, BV100, BV100HD, BV140, BV175 or
BV210
Provides 2 alternative and simultaneous power sources:
1.
a nominal 14.8V through an XLR connector (pin 4 -pin 1)
2.
a nominal 14.8V through a D-Tap connector
Versatile and ideal solution for cameras, portable light systems and additional equipment -
powers several devices from the same battery.
Special cables are available to fit compatible camcorders
