Rack Mounting (Optional Feature)
Rack Mounting (Optional Feature)
Rack mounting kits are available for both 19 and 23 inch racks.
To rack mount the Unit, follow the instructions below:
1. Attach bracket ears to rack mounting bracket using four #8-32 x 3/16" screws
on each side.
Bracket Ear
Left Side View
