TOURnado™ IP Beam User Manual Rev. A © Copyright 2014 Blizzard Lighting, LLC
2. MEET THE TOURNADO™ IP BEAM LED PAR
CONTROL FEATURES
• RGBW color mixing via 7x 15W Red/Green/Blue/White 4-in-1 LEDs
• LED control panel with 4 touch sensitive electronic buttons
• Super-sharp 8° beam angle
• Variable electronic dimming & strobe
• Built-in color & chase macros via DMX
• Built-in automated programs via master/slave
• RGBW color mixing ability in standalone mode
• RGBW & Strobe (5-Ch), Dimmer, RGBW & Strobe (6-Ch), & Extended
with Dimmer, RGBW, Strobe, & 32-bit dimming (9-Ch) DMX Profiles
ADDITIONAL FEATURES
• Rugged and well-built (It hits the gym regularly)
• Convection cooled cast aluminum housing
• Dual mounting brackets for positioning flexibility
• Flicker-free constant-current 500MA LED driver
• IP rated locking power and 3-pin DMX connections
DMX Quick Reference - 9 / 6 Channel Mode
Channel 9 Channel 6 Channel
1 Dimmer Dimmer
2 Red Intensity Red Intensity
3 Green Intensity Green Intensity
4 Blue Intensity Blue Intensity
5 White Intensity White Intensity
6 Strobe Strobe
7 Static Colors + Auto ---
8 Built-in Programs ---
9 32-bit Dimming ---
DMX Quick Reference - 5 Channel Mode
Channel 5 Channel
1
Red Intensity
2 Green Intensity
3 Blue Intensity
4 White Intensity
5 Strobe
