ToughSTICK™ RGBAW Manual - Rev. B
Copyright (c) 2012 Blizzard Lighting, LLC
Troubleshooting
Symptom
Solution
Beam is Dim
Check optical system and clean excess dust/grime. Also
ensure that the 220V/110V switch is in the correct position,
if applicable.
No Light Output Check to ensure fi xture is operating under correct mode,
IE auto/DMX/Etc., if applicable. Contact service for more
information.
Chase Speed
Too Fast/Slow
Check to ensure proper setup of speed adjustment.
No Power
Check fuse, AC cord and circuit for malfunction.
Blown Fuse
Check AC cord and circuit for damage, verify that moving
parts are not restricted and that unit’s ventilation is not
obstructed
Fixture Not
Responding /
Responding Er-
raticly
Make sure all connectors are seated properly and securely.
Use Only DMX Cables.
Install a Terminator.
Check all cables for defects.
Reset fi xture(s).
If your problem isn’t listed, or if problems persist,
please contact support: [email protected].
DMX Values In-Depth (7-Channel Mode)
Channel
Value
What It Does
1
000 <--> 010 Dimmer
011 <--> 051 Strobe (Slow <--> Fast)
052 <--> 091 Color Fade In/Out
092 <--> 131 Program #1: 15-Color Chase, Full Bar (Slow <--> Fast)
132 <--> 150 Program #2: Red + G/B/A/W Pixel Chase (Slow <--> Fast)
151 <--> 169 Program #3: 5-Color Pixel Chase (Slow <--> Fast)
170 <--> 189 Program #4: Red+Green + B/A/W Pixel Chase (Slow <--> Fast)
190 <--> 209 Program #5: Red/Green/Blue Pixel Chase (Slow <--> Fast)
210 <--> 229 Program #6: Blue/Amber/White Pixel Chase (Slow <--> Fast)
230 <--> 249 Program #7: Inverse Color Pixel Chase (Slow <--> Fast)
250 <--> 255 All Programs Chase (Slow <--> Fast)
2
000 <--> 255 Dimmer (0% <--> 100%)
3
000 <--> 255 Red Intensity (0% <--> 100%)
4
000 <--> 255 Green Intensity (0% <--> 100%)
5
000 <--> 255 Blue Intensity (0% <--> 100%)
6
000 <--> 255 Amber Intensity (0% <--> 100%)
7
000 <--> 255 White Intensity (0% <--> 100%)
