Torrent™ FZ User Manual - Rev. A (c) 2014 Blizzard Lighting, LLC
DMX Channel Value
Standard
Ch. Mode
Basic Ch.
Mode
Channel
Value
What it does
1 1 000 <-> 255 Pan
2 000 <-> 255 Pan Fine (16-Bit Pan)
3 2 000 <-> 255 Tilt
4 000 <-> 255 Tilt Fine (16-Bit Tilt)
5 3
000 <-> 015
016 <-> 031
032 <-> 047
048 <-> 063
064 <-> 079
080 <-> 095
096 <-> 111
112 <-> 127
128 <-> 189
190 <-> 193
194 <-> 255
Color Mode 1
Open
Color 1
Color 2
Color 3
Color 4
Color 5
Color 6
Color 7
Color Wheel Scroll (Clockwise, Fast <-> Slow)
Stop
Color Wheel Scroll (CCW, Slow <-> Fast)
5 3
000 <-> 007
008 <-> 015
016 <-> 023
024 <-> 031
032 <-> 039
040 <-> 047
048 <-> 055
056 <-> 063
064 <-> 071
072 <-> 079
080 <-> 087
088 <-> 095
096 <-> 103
104 <-> 111
112 <-> 119
120 <-> 127
128 <-> 189
190 <-> 193
194 <-> 255
Color Mode 1
Open
White + Color 1
Color 1
Color 1 + Color 2
Color 2
Color 2 + Color 3
Color 3
Color 3 + Color 4
Color 4
Color 4 + Color 5
Color 5
Color 5 + Color 6
Color 6
Color 6 + Color 7
Color 7
Color 7 + White
Color Wheel Scroll (Clockwise, Fast <-> Slow)
Stop
Color Wheel Scroll (CCW, Slow <-> Fast)
6 4
000 <-> 009
010 <-> 019
020 <-> 029
030 <-> 039
040 <-> 049
050 <-> 059
060 <-> 069
070 <-> 079
080 <-> 099
100 <-> 119
120 <-> 139
140 <-> 159
160 <-> 179
180 <-> 199
200 <-> 219
220 <-> 255
Gobo Wheel #1
Open
Gobo 1
Gobo 2
Gobo 3
Gobo 4
Gobo 5
Gobo 6
Gobo 7
Gobo Shake 1
Gobo Shake 2
Gobo Shake 3
Gobo Shake 4
Gobo Shake 5
Gobo Shake 6
Gobo Shake 7
Gobo Wheel Spin (Slow <-> Fast)
7 5
000 <-> 127
028 <-> 189
190 <-> 193
194 <-> 255
Gobo Rotation
Gobo Indexing
Clockwise Rotation (Fast <-> Slow)
Rotation Stop
Counter-Clockwise Rotation (Slow <-> Fast)
