Page 18
ToughPAR 1 Manual Rev. A Copyright (c) 2011 Blizzard Lighting, LLC
Tech Specs!
Weight & Dimensions
Length
10 inches (254 mm)
Width 7.75 inches (197 mm)
Height 7.75 inches (197 mm)
Weight 5.25 lbs (2.4 kg)
Power
Operating Voltage
90-230VAC, 50-60 Hertz
Fuse 3A 250V
Power Consumption 140W
Light Source
LED
36x 1W Red/Green/Blue LEDs 100,000
hours.
Optical
Beam Angle
15 degree optics standard
13 degree beam
19 degree fi eld
Luminous Intensity 10,220 Lux @ 1m (25 degree optics)
Thermal
Max. Operating Temp.
104 degrees F (40 degrees C) ambient
Control
Protocol
USITT DMX-512
DMX Channels 9
Input 3-pin XLR Male
Output 3-pin XLR Female
Other Operating Modes
Standalone, Master/Slave, Sound Active,
Color Preset
Coolness Factor
Leventy Billion Percent
Warranty
2-year limited warranty, does not cover mal-
function caused by damage to LED’s.
Page 3
ToughPAR 1 Manual Rev. A Copyright (c) 2011 Blizzard Lighting, LLC
1. GETTING STARTED
What’s In The Box?
• 1 x ToughPAR™ 1 IP65-Rated LED PAR Fixture
• A weather-resistant AC Power Cord
• A weather-resistant DMX Input Cord
• A weather-resistant DMX Output Cord
• This Lovely User Manual
Getting It Out Of The Box
Congratulations on purchasing one tough mother of a PAR Can! Now
that you’ve got your ToughPAR™ (or hopefully, ToughPARS!), you
should carefully unpack the box and check the contents to ensure that
all parts are present and in good condition. If anything looks as if it
has been damaged in transit, notify the shipper immediately and keep
the packing material for inspection. Again, please save the carton and
all packing materials. If a fi xture must be returned to the factory, it is
important that the fi xture be returned in the original factory box and
packing.
Powering Up!
All fi xtures must be powered directly off a switched circuit and cannot
be run off a rheostat (variable resistor) or dimmer circuit, even
if the rheostat or dimmer channel is used solely for a 0% to
100% switch.
AC Voltage Switch - Not all fi xtures have a voltage select switch, so
please verify that the fi xture you receive is suitable for your local pow-
er supply. See the label on the fi xture or refer to the fi xture’s specifi -
cations chart for more information. A fi xture’s listed current rating is
its average current draw under normal conditions. Check the fi xture or
device carefully to make sure that if a voltage selection switch exists
that it is set to the correct line voltage you will use.
Warning! Verify that the voltage select switch on your unit
matches the line voltage applied. Damage to your fi xture may
result if the line voltage applied does not match the voltage
indicated on the voltage selector switch. All fi xtures must be
connected to circuits with a suitable Ground (Earthing).
Getting A Hold Of Us
If something is wrong, just give us a call or send an email.
We’ll be happy to help, honest.
Blizzard Lighting
PO Box 1874, Brookfi eld, WI 53008 USA
[email protected]
www.blizzardlighting.com
