The Puck CSI Xtreme User Manual Rev. B Copyright (c) 2014 Blizzard Lighting, LLC
2. MEET THE PUCK CSI™ XTREME
CONTROL FEATURES
• High output UV via 36x 3w 390-410nm UV LEDs
• Full on UV LED intensity + 4 separate LED pixel patterns
• Variable electronic strobe
• Variable electronic dimmer
• Built-in automated programs via DMX and master/slave
• Built-in sound active programs
ADDITIONAL FEATURES
• Lightweight and compact (It kept its New Years’ resolution!)
• 4-Button LED control panel for easy programming
• Dual bracket for flexibility in mounting
• Power outlet for fixture linking
DMX Quick Reference (7-Channel Mode)
Channel Channel Value What It Does
1
000 <-> 255 Master Dimmer (0% <--> 100%)
2 000 <-> 255 Pattern 1 Intensity (0% <--> 100%)
3 000 <-> 255 Pattern 2 Intensity (0% <--> 100%)
4 000 <-> 255 Pattern 3 Intensity (0% <--> 100%)
5 000 <-> 255 Pattern 4 Intensity (0% <--> 100%)
6 000 <-> 255 Strobe (slow <--> fast)
7 000 <-> 255 Auto Mode (slow <--> fast)
DMX Quick Reference (4-Channel Mode)
Channel Channel Value What It Does
1
000 <-> 255 Pattern 1 Intensity (0% <--> 100%)
2 000 <-> 255 Pattern 2 Intensity (0% <--> 100%)
3 000 <-> 255 Pattern 3 Intensity (0% <--> 100%)
4 000 <-> 255 Pattern 4 Intensity (0% <--> 100%)
