The Puck™ QFX Manual Rev. A Copyright (c) 2012 Blizzard Lighting, LLC
DMX Quick Reference (16-Channel Mode)
Channel What It Does
1
Pixel 1 - Red Intensity (0% <--> 100%)
2 Pixel 1 - Green Intensity (0% <--> 100%)
3 Pixel 1 - Blue Intensity (0% <--> 100%)
4 Pixel 1 - White Intensity (0% <--> 100%)
5 Pixel 2 - Red Intensity (0% <--> 100%)
6 Pixel 2 - Green Intensity (0% <--> 100%)
7 Pixel 2 - Blue Intensity (0% <--> 100%)
8 Pixel 2 - White Intensity (0% <--> 100%)
9 Pixel 3 - Red Intensity (0% <--> 100%)
10 Pixel 3 - Green Intensity (0% <--> 100%)
11 Pixel 3 - Blue Intensity (0% <--> 100%)
12 Pixel 3 - White Intensity (0% <--> 100%)
13 Pixel 4 - Red Intensity (0% <--> 100%)
14 Pixel 4 - Green Intensity (0% <--> 100%)
15 Pixel 4 - Blue Intensity (0% <--> 100%)
16 Pixel 4 - White Intensity (0% <--> 100%)
2. MEET ThE PUCk™ QFX FLAT LED PAR FIXTURE
MAIn FEATURES
• Superior RGBW color mixing via 12 x 10-watt quad-color RGBW LED’s
• DMX controllable full panel and 4-pixel effects (3 LED’s per pixel)
• User selectable 3/4/9 or 16-channel DMX modes
• Built-in automated programs via master/slave
• Built-in sound activated programs via master/slave
• Variable electronic strobe
• Variable electronic dimmer (0 – 100%)
• 4 sound active modes & 2 auto modes, full panel & pixel
• Internal microphone sensitivity adjustment
• Easy to use LED control panel
• Running hours display
• Rugged all-metal case with dual mounting yokes
• IEC power in and daisy chain connections to connect additional units (MAX 4 UNITS
PER CHAIN)
• Able to directly power the wiCICLE® wireless system via DMX
• Power, DMX connections and LED control panel are all in places which allows use in
ANY position, including flat on the floor!
