Tech Specs!
Weight & Dimensions
Length 9.02 inches (229 mm)
Width 6.5 inches (165 mm)
Height 8.98 inches (228 mm)
Weight 7.28 lbs (3.3 kg)
Power
Operating Voltage 120VAC 60Hz
Power Consumption 126W, 1.69A
Light Source
LED 18x 10W 4-in-1 LEDs 100,000 hours.
Optical
Beam Angle 25 degree optics standard
26 degree beam
30 degree field
Luminous Intensity 1m 2m
Red 8,850 Lux 2,895 Lux
Green 8,600 Lux 2,460 Lux
Blue 8,900 Lux 2,650 Lux
White 10,120 Lux 2,900 Lux
Thermal
Max. Operating Temp. 104 degrees F (40 degrees C) ambient
Control
Protocol USITT DMX-512
DMX Channels 3/4/5/8/9
Input 3-pin XLR Male
Output 3-pin XLR Female
Other Operating Modes Standalone, Master/Slave, Sound Active, Color Preset
Coolness Factor
Leventy Billion Percent
Warranty 2-year limited warranty, does not cover malfunction
caused by damage to LED’s.
DISCLAIMER:
The power connector fitted to the fixture and fixture cord are designed for compatibility with
products manufactured by Neutrik AG, Neutrik USA and their related entities, however they
are not manufactured by, affiliated with or endorsed by Neutrik AG, Neutrik USA, or any re-
lated entity. Neutrik® and powerCON® are registered trademarks of Neutrik AG.
