Motif Sketch™ Manual Rev. A Copyright (c) 2012 Blizzard Lighting, LLC
Figure 1: The Motif Sketch™ Pin-Up Picture
Figure 2: The Remote Control
AC Power In
DMX In
DMX Out
R/G/B Dimming Buttons
Blackout
Auto Run
Select Program
Flash
Speed
DMX Mode
Sound Active
Slave Mode
Set Address
Buttons (0-9)
+/- Buttons
TRI-Color RGB LEDs
AC Power Out
