Page 15
FURY Manual Rev. A Copyright (c) 2010 Blizzard Lighting, LLC
DMX Channel Values (7 Channel Mode)
Channel Channel Value Does...
1 000 <-> 255 Pan
2 000 <-> 255 Tilt
3
000 <-> 003
004 <-> 007
008 <-> 215
216 <-> 255
Strobe
Off
Open
Strobe (Fast <-> Slow)
Open
4 000 <-> 255
Dimmer
0 <-> 100%
5
000 <-> 008
009 <-> 013
014 <-> 019
020 <-> 025
026 <-> 031
032 <-> 037
038 <-> 043
044 <-> 052
053 <-> 064
065 <-> 076
077 <-> 088
089 <-> 100
101 <-> 112
113 <-> 124
125 <-> 128
129 <-> 191
192 <-> 255
Color
White
Magenta
Yellow
Green
Purple
Blue
Lime Green
White/Magenta (Split)
Magenta/Yellow (Split)
Yellow/Green (Split)
Green/Purple (Split)
Purple/Blue (Split)
Blue/Lime Green (Split)
Lime Green/White (Split)
White
CCW Scroll (Slow <-> Fast)
CW Scroll (Slow <-> Fast)
6
000 <-> 007
008 <-> 015
016 <-> 023
024 <-> 031
032 <-> 039
040 <-> 047
048 <-> 055
056 <-> 063
064 <-> 071
072 <-> 079
080 <-> 087
088 <-> 095
096 <-> 103
104 <-> 111
112 <-> 119
120 <-> 127
128 <-> 191
192 <-> 255
Gobo
Open
Gobo 1
Gobo 2
Gobo 3
Gobo 4
Gobo 5
Gobo 6
Gobo 7
Gobo Shake 7
Gobo Shake 6
Gobo Shake 5
Gobo Shake 4
Gobo Shake 3
Gobo Shake 2
Gobo Shake 1
Open
Gobo Wheel Spin CW (Slow <-> Fast)
Gobo Wheel Spin CCW (Slow <-> Fast)
7 000 <-> 255
Focus
0 <-> 100%
Page 16
FURY Manual Rev. A Copyright (c) 2010 Blizzard Lighting, LLC
Troubleshooting
Symptom Solution
Fixture Auto-
Shut Off
Check the fan in the fi xture. If it is stopped or moving
slower than normal, the unit may have shut itself off due to
high heat. This is to protect the fi xture from overheating.
Clear the fan of obstructions, or return the unit for service.
Beam is Dim Check optical system and clean excess dust/grime. Also
ensure that the 220V/110V switch is in the correct position,
if applicable.
No Light Output Check to ensure fi xture is operating under correct mode, IE
sound active/auto/DMX/Etc., if applicable. Contact service
for more information.
Chase Speed
Too Fast/Slow
Check to ensure proper setup of speed adjustment.
No Power Check fuse, AC cord and circuit for malfunction.
Blown Fuse Check AC cord and circuit for damage, verify that moving
parts are not restricted and that unit’s ventilation is not
obstructed
Slow Movement Verify that 220V/110V switch is in the correct position, if
applicable. Also check that speed channels are set appropri-
ately.
No Response to
Audio
Verify that the fi xture is in “Sound Active” mode.
Adjust Audio Sensitivity, If Applicable.
Fixture Not
Responding /
Responding Er-
raticly
Make sure all connectors are seated properly and securely.
Use Only DMX Cables.
Install a Terminator.
Check all cables for defects.
Reset fi xture(s).
Intermittant
Lamp
Check lamp for properly installation.
Relamp, lamp may have reached end of life.
Remote Doesn’t
Work
Verify remote control cable is installed properly and securely.
Verify remote is correct type (CA-9 or other as applicable.)
Fixture Moving
On Its Own
Verify proper mode of operation. Is the fi xture in “Auto”
mode?
If your problem isn’t listed, or if problems persist,
please contact support: [email protected].
