Helios™ Moving Head Spot - Rev. A
(c) 2014 Blizzard Lighting, LLC
DMX Channel Values
Short
Mode
Standard
Mode
Extended
Mode
Channel
Value
What it does
1
1
1
000 <-> 255 Pan
...
2
2
000 <-> 255 Pan Fine (16-Bit Pan)
2
3
3
000 <-> 255 Tilt
...
4
4
000 <-> 255 Tilt Fine (16-Bit Tilt)
...
5
5
000 <-> 255 Movement Speed (fast <--> slow)
3
6
6
000 <-> 009
010 <-> 255
No Function
Dimmer
4
7
7
000 <-> 004
005 <-> 009
010 <-> 199
200 <-> 204
205 <-> 224
225 <-> 229
230 <-> 249
250 <-> 255
No Function
No Strobe (Open)
Strobe (slow <--> fast)
No Strobe (Open)
Random Strobe (slow <--> fast)
No Strobe (Open)
Random Color Strobe (slow <--> fast)
No Strobe (Open)
5
8
8
000 <-> 255 Red (8-bit)
...
...
9
000 <-> 255 Red Fine (16-bit)
6
9
10
000 <-> 255 Green (8-bit)
...
...
11
000 <-> 255 Green Fine (16-bit)
7
10
12
000 <-> 255 Blue (8-bit)
...
...
13
000 <-> 255 Blue Fine (16-bit)
8
11
14
000 <-> 255 White (8-bit)
...
...
15
000 <-> 255 White Fine (16-bit)
...
12
16
000 <-> 009
010 <-> 019
020 <-> 029
030 <-> 039
040 <-> 049
050 <-> 059
060 <-> 069
070 <-> 079
080 <-> 089
090 <-> 099
100 <-> 109
110 <-> 119
120 <-> 129
130 <-> 139
140 <-> 255
Built-in Colors
Open
Color Temperature = 2700k
Color Temperature = 3200k
Color Temperature = 4200k
Color Temperature = 5600k
Color Temperature = 8000k
Red
Orange
Green
Blue
Yellow
Cyan
Magenta
White
Multi-Colors
9
13
17
000 <-> 009
010 <-> 019
020 <-> 029
030 <-> 039
040 <-> 049
050 <-> 059
060 <-> 069
070 <-> 079
080 <-> 089
090 <-> 099
100 <-> 109
110 <-> 119
120 <-> 129
130 <-> 139
140 <-> 149
150 <-> 202
203 <-> 255
Gobo Wheel #1
Open (White)
Gobo 1
Gobo 2
Gobo 3
Gobo 4
Gobo 5
Gobo 6
Gobo 7
Gobo Shake 1 (slow <--> fast)
Gobo Shake 2 (slow <--> fast)
Gobo Shake 3 (slow <--> fast)
Gobo Shake 4 (slow <--> fast)
Gobo Shake 5 (slow <--> fast)
Gobo Shake 6 (slow <--> fast)
Gobo Shake 7 (slow <--> fast)
Clockwise Rotation (fast <-> slow)
Counter-Clockwise Rotation (slow <-> fast)
10
14
18
000 <-> 127
028 <-> 190
191 <-> 192
193 <-> 255
Gobo #1 Rotation
Gobo Indexing
Clockwise Rotation (Fast <-> Slow)
Rotation Stop
Counter-Clockwise Rotation (Slow <-> Fast)
