Control Panel Menu Structure

Main Function

Sub Function

Selection

What It Does...

Address Setup

N/A

=001 <-> =512

Sets the DMX address

Load Default

N/A

=NO / =YES

Loads the fixtures default factory settings

Information

Temperature

Displays the temperature at the LED heat sink

Version

Displays the fixtures firmware version

View DMX Value

Displays DMX values, channels 001 - 512

Product ID

Displays the fixtures ID number

Fixture Hours

Displays the current total fixture runtime hours

Advanced

Access Code

=000 <-> =255

Code: 008, enables advanced editing

Mic Sensitivity

=0% <-> =100%

Built-in microphone sensitivity level adjustment

Adjust Red

=000 <-> =255

Red Intensity (0% <--> 100%)

Green

=000 <-> =255

Green Intensity (0% <--> 100%)

Blue

=000 <-> =255

Blue Intensity (0% <--> 100%)

White

=000 <-> =255

White Intensity (0% <--> 100%)

Fixed Gobo Wheel

=-127 <-> =+127

Fine incremental fixed gobo wheel adjustments

Rot. Gobo Wheel

=-127 <-> =+127

Fine incremental rotating wheel adjustments

Focus

=-127 <-> =+127

Fine incremental focus adjustments

Prism

=-127 <-> =+127

Fine incremental prism adjustments

Tilt

=-127 <-> =+127

Fine incremental tilt adjustments

Pan

=-127 <-> =+127

Fine incremental pan adjustments

Option

Settings

Pan Tilt Swap

=OFF / =ON

Swaps pan/tilt settings

Lost DMX

=Clear Value

=Hold Value

When DMX signal is lost, either clear or hold the last

DMX signal received

Display Setup

=Display Invert

=Language

=Display Off

Adjusts the setttings to invert the display (on/off),

change the language (English or Chinese), or turn

off the LCD display (on/off).

Pan Invert

=OFF / =ON

Inverts the fixtures pan movments

Tilt Invert

=OFF / =ON

Inverts the tilt movments

Option Mode

DMX Mode

Short Mode

Sets fixture to run in 17-channel DMX mode

Standard Mode

Sets fixture to run in 21-channel DMX mode

Extended Mode

Sets fixture to run in 25-channel DMX mode

Music Mode

=001 <-> =004

Sound active mode (choose built-in program 1-4)

Slave Same Mode

Slave mode

Slave Sync Mode

Slave mode (choose built-in program 1-4)

Master Mode

Master auto mode (choose built-in program 1-4)

Auto Mode

Single auto mode (choose built-in program 1-4)

Manual

Operation

Pan

=000 <-> =255

Allows you to manually set the fixture to a fixed

setting using the DMX values for each channel. For

more information on the DMX values available for

each channel, see pages 12-13.

Tilt

=000 <-> =255

Red

=000 <-> =255

Green

=000 <-> =255

Blue

=000 <-> =255

White

=000 <-> =255

Strobe

=000 <-> =255

Fixed Gobo Wheel

=000 <-> =255

Rot. Gobo Wheel

=000 <-> =255

Gobo Rotation

=000 <-> =255

Prism

=000 <-> =255

Prism Rot

=000 <-> =255

Focus

=000 <-> =255

Reset

Reset Pan & Tilt

Resets pan and tilt

Reset Effects

Resets all of the effects

Reset Complete

Resets all
