Blizzard Lighting 252 COLORStorm - Manual (Page 6)

Page 11
COLORStorm 252 Manual Rev. B Copyright (c) 2010 Blizzard Lighting, LLC
DMX Channel Values (3 Channel Mode 1)
Channel Channel Value Does...
1 000 <-> 017 Red (All Segments)
2 000 <-> 255 Green (All Segments)
3 000 <-> 255 Blue (All Segments)
DMX Channel Values (3 Channel Mode 2)
Channel Channel Value Does...
1
000 <-> 017
018 <-> 035
036 <-> 053
054 <-> 071
072 <-> 089
090 <-> 107
108 <-> 125
126 <-> 143
144 <-> 161
162 <-> 179
180 <-> 197
198 <-> 215
216 <-> 233
234 <-> 255
Mode/Chase Select
Color Macro Mode
Chase #1
Chase #2
Chase #3
Chase #4
Chase #5
Chase #6
Chase #7
Chase #8
Chase #9
Chase #10
Chase #11
Chase #12
Sound Active Mode
2 000 <-> 255
Color Macro Select/Chase Speed/Sound Sensitivity
Color Macro Select (Channel 1 = 000 <-> 017)
Chase Speed (Slow <-> Fast) (Channel 1 = 018 <-> 233)
Sound Sensitivity (Least <-> Most) (Channel 1 = 234 <-> 255)
3 000 <-> 010
011 <-> 255
Strobe
No Function
Strobe (Slow <-> Fast)
DMX Channel Values (9 Channel Mode)
Channel Channel Value Does...
1 000 <-> 255 Red (Segment #1)
2 000 <-> 255 Green (Segment #1)
3 000 <-> 255 Blue (Segment #1)
4 000 <-> 255 Red (Segment #2)
5 000 <-> 255 Green (Segment #2)
6 000 <-> 255 Blue (Segment #2)
7 000 <-> 255 Red (Segment #3)
8 000 <-> 255 Green (Segment #3)
9 000 <-> 255 Blue (Segment #3)
Page 12
COLORStorm 252 Manual Rev. B Copyright (c) 2010 Blizzard Lighting, LLC
Troubleshooting
Symptom Solution
Fixture Auto-
Shut Off
Check the fan in the fi xture. If it is stopped or moving
slower than normal, the unit may have shut itself off due to
high heat. This is to protect the fi xture from overheating.
Clear the fan of obstructions, or return the unit for service.
Beam is Dim Check optical system and clean excess dust/grime. Also
ensure that the 220V/110V switch is in the correct position,
if applicable.
No Light Output Check to ensure fi xture is operating under correct mode, IE
sound active/auto/DMX/Etc., if applicable. Contact service
for more information.
Chase Speed
Too Fast/Slow
Check to ensure proper setup of speed adjustment.
No Power Check fuse, AC cord and circuit for malfunction.
Blown Fuse Check AC cord and circuit for damage, verify that moving
parts are not restricted and that unit’s ventilation is not
obstructed
Slow Movement Verify that 220V/110V switch is in the correct position, if
applicable. Also check that speed channels are set appropri-
ately.
No Response to
Audio
Verify that the fi xture is in “Sound Active” mode.
Adjust Audio Sensitivity, If Applicable.
Fixture Not
Responding /
Responding Er-
raticly
Make sure all connectors are seated properly and securely.
Use Only DMX Cables.
Install a Terminator.
Check all cables for defects.
Reset fi xture(s).
Intermittant
Lamp
Check lamp for properly installation.
Relamp, lamp may have reached end of life.
Remote Doesn’t
Work
Verify remote control cable is installed properly and securely.
Verify remote is correct type (CA-9 or other as applicable.)
Fixture Moving
On Its Own
Verify proper mode of operation. Is the fi xture in “Auto”
mode?
If your problem isn’t listed, or if problems persist,
please contact support: [email protected].
