CobZilla™ Bright White 5X5 Matrix Manual Rev. A
Copyright (c) 2010-14 Blizzard Lighting, LLC
Figure 1: The COBZilla™ Bright White 5X5 Matrix Pin-Up Pic-
ture
25 High Power
Cool White COB
LED’s
Tough Steel
Enclosure
Figure 2: The Rear Connections
AC Power IN/
Power Out
DMX In
DMX Out
LED Control Panel
Adjustment
Knobs
Safety Cable
Attachment
Point
Fixture Link Bracket Mount
