DMX Mode
Allows the unit to be controlled by any universal DMX controller. If you are unfamiliar with
DMX, please read the DMX Primer on page #16.
1.) The COBZilla™ Bright White 5X5 Matrix is capable of operating
with 1, 4, 25, or 28 DMX channels. To select the channel mode that you desire,
First press the button to select
d001
on the LED Readout.
Then press the button to select channel mode,
1-ch, 4-ch,
25ch
or
28ch
. Use the or to select desired channel.
Auto, Master/Slave, Sound Active & Character Modes:
Allows a single or Master/Slaved units to run factory installed programs at user selectable
speeds.
1.) To set the fixture in Auto mode, select
AUTO
using the button.
2.) To use the fixture’s built-in programs, select
Pr.01-27
, using the
button then the and buttons to choose desired pro-
gram. Press the button to exit out of the menu.
3.) Each fixture is a master by default. To set the fixture as a slave, use the
SLAv,
then press the button select
a mode.
SLAv 1 -1, 1 - 2, 2 -1, 2 - 2
. Using the and
buttons. When the user joins four devices, as shown below, the
devices will work as one unit.
Host
1-2
2-1 2-2
4.) Press the button to exit out of the menu.
Sound Active Mode:
1.) To use sound active mode, select
SouD
by pressing .
2.) Press the button to change built-in program
SU.00-31
by
using the and buttons.
3.) Press the button to exit out of the menu.
Character Mode (Individual Letters and Numbers Mode):
Allows a single fixture to display a variety of individual letters or numbers without a DMX
controller. (Would be really cool with multiple fixtures! Hint... Hint...)
1.) Press the button to reach
ChAr.
Then press the but-
ton to select Letter mode or Number mode.
2.) Use the button to select which letter or number you want the
fixture to display. Use the and buttons to select
PA A - Z
under
Lett
or
PA 0 - 9
under
nUbe.
3.) Press the button to save and exit.
