Wideband Power Sensor
5012D, 5016D, 5017D, 5018D, 5019D
Wideband Power Sensor
5012D, 5016D, 5017D, 5018D, 5019D
GENERAL SPECIFICATIONS
Connector
Power Supply
Impedance
Weight
Dimensions HxWxD
[inches (mm)]
Data Logging
Operating Temps
[°C(°F)]
Storage Temps
[°C(°F)]
Mechanical Shock
& Vibration
CE
INTERFACES
DPM
PC Interface (1)
PC Interface (2)
N Female (Both)
USB Port: Less than one low-power
USB load DC Input Connector: 7-18
VDC at less than 0.1A
50 Ohms (nominal)
1.2 lb. maximum
4.8” x 4.6” x 1.3”
(122 mm x 117 mm x 33 mm)
Requires 5000-XT or VPM3
-10° to 50°C (+14° to + 122°F)
-40° to + 80°C (-40° to +176°F)
IAQ MIL-PRF-28800F class3
EMC EN 61326-1-2006
DB9 proprietary interface
RS-232, 9600 Baud, no parity,
8 data bits, 1 stop bit, DB9
USB 2.0 Type B
Frequency Range
Power Range
Insertion VSWR
Insertion Loss
Directivity
AVERAGE POWER
Average Forward
Power Range
*Accuracy, Average
Forward Power
Minimum Forward
Power for Reflected
Measurement
Return Loss
VSWR
5012D
5016D
5017D
5018D
5019D
5012D
5016D
5017D
5018D
5019D
5012D
5016D
5017D
5018D
5019D
5012D
5016D
5017D
5018D
5019D
5012D
5016D
5017D
5018D
5019D
5012D
5016D
5017D
5018D
5019D
5012D
5016D
5017D
5018D
5019D
5012D
5016D
5017D
5018D
5019D
5012D
5016D
5017D
5018D
5019D
5012D
5016D
5017D
5018D
5019D
350 MHz - 4.0 GHz
350 MHz - 4.0 GHz
25 MHz - 1.0 GHz
150 MHz - 4.0 GHz
25 MHz - 1.0 GHz
150 mW - 150 Watts Avg, 400 Watts Peak
25 mW - 25 Watts Avg, 60 Watts Peak
500mW - 500 Watts Avg, 1300 Watts Peak
100 mW - 25 Watts Avg, 60 Watts Peak
100 mW - 100 Watts, 260 Watts Peak
<1.05 from 0.35 to 2.5 GHz, <1.10 from 2.5 to 4 GHz
<1.05 from 0.35 to 2.5 GHz, <1.10 from 2.5 to 4 GHz
<1.05
<1.05 from 0.35 to 2.5 Ghz, <1.10 from 2.5 to 4 GHz
<1.05
<0.05 dB from 0.35 to 1.0 GHz, <0.1 dB from 1 to 4 GHz
<0.05 dB from 0.35 to 1.0 GHz, <0.1 dB from 1 to 4 GHz
<0.05 dB
<0.05 dB from 0.35 to 1.0 GHz, <0.1 dB from 1 to 4 GHz
<0.05 dB
30 dB up to 3.0 GHz, 28 dB from 3.0 to 4.0 GHz
30 dB up to 3.0 GHz, 28 dB from 3.0 to 4.0 GHz
28 dB up to 100 MHz, 30 dB from 100 to 1000 MHz
30 dB up to 3.0 GHz, 28 dB from 3.0 to 4.0 GHz
28 dB up to 100 MHz, 30 dB from 100 to 1000 MHz
150 mW - 150 Watts Avg, 400 Watts Peak
25 mW - 25 Watts Avg, 60 Watts Peak
500 mW - 500 Watts Avg, 1300 Watts Peak
100 mW - 25 Watts Avg, 60 Watts Peak
100 mW - 100 Watts, 260 Watts Peak
± 4% of reading, + 0.05 W
± 4% of reading, + 0.008 W
± 4% of reading, + 0.17 W
± 4% of reading, + 0.008 W
± 4% of reading, + 0.04 W
0.5 W
0.1 W
0.5 W
0.1 W
0.3 W
0.0 to 23 dB
0.0 to 23 dB
0.0 to 23 dB
0.0 to 23 dB
0.0 to 23 dB
1.15 to 99.9
1.15 to 99.9
1.15 to 99.9
1.15 to 99.9
1.15 to 99.9
BURST AVERAGE POWER
Burst Average
Power Range
5012D
5016D
5017D
5018D
5019D 4W - 150 Watts Avg
.7W - 25 Watts Avg
13.5W - 500 Watts Avg
.7 W - 25 Watts Avg
2.7 W - 100 Watts Avg
Burst Width 5012D
5016D
5017D
5018D
5019D
1 μs to 5 ms
1 μs to 5 ms
1 μs to 5 ms
1 μs to 5 ms
1 μs to 5 ms
Repetitions Rate 5012D
5016D
5017D
5018D
5019D
5 Hz, Min
5 Hz, Min
5 Hz, Min
5 Hz, Min
5 Hz, Min
Duty Cycle (D) 5012D
5016D
5017D
5018D
5019D
.002 to 1.0
.002 to 1.0
.002 to 1.0
.002 to 1.0
.002 to 1.0
*Accuracy, Burst
Average Power
5012D
5016D
5017D
5018D
5019D ± 6% of reading, + 0.05 W
± 6% of reading, + 0.008 W
± 6% of reading, + 0.17W
± 6% of reading, + 0.008 W
± 6% of reading, + 0.04 W
PEAK ENVELOPE POWER
Peak Envelope
Power Range
5012D
5016D
5017D
5018D
5019D 4.0 - 400 W
0.7 - 60 W
13.5 - 1300 W
0.7 - 60 W
2.7 - 260 W
*PEAK ENVELOPE POWER ACCURACY
burst width
> 200 μs
5012D
5016D
5017D
5018D
5019D ± 7% of reading, + 0.20 W
± 7% of reading, + 0.05 W
± 7% of reading, + 0.70 W
± 7% of reading, + 0.05 W
± 7% of reading, + 0.13 W
1 μs < burst
width < 200 μs
5012D
5016D
5017D
5018D
5019D ± 10% of reading, + 0.40 W
± 10% of reading, + 0.10 W
± 10% of reading, + 1.40 W
± 10% of reading, + 0.10 W
± 10% of reading, + 0.26 W
0.5 μs < burst
width < 1 μs
5012D
5016D
5017D
5018D
5019D ± 15% of reading, + 0.40 W
± 15% of reading, + 0.10 W
± 15% of reading, + 1.40 W
± 15% of reading, + 0.10 W
± 15% of reading, + 0.26 W
burst width
< 0.5 μs
5012D
5016D
5017D
5018D
5019D ± 20% of reading, + 0.40 W
± 20% of reading, + 0.10 W
± 20% of reading, + 1.40 W
± 20% of reading, + 0.10 W
± 20% of reading, + 0.26 W
CREST FACTOR
Crest Factor
Measurement Range
5012D
5016D
5017D
5018D
5019D 150 mW - 150 Watts
25 mW - 25 Watts
500 mW - 25 Watts
25 mW - 25 Watts
100 mW - 100 Watts
*Accuracy, Crest Factor 5012D
5016D
5017D
5018D
5019D
Linear Sum of Peak and
Average Power Accuracies
COMPLEMENTARY CUMULATIVE DISTRIBUTION
FUNCTION (CCDF)
CCDF Measurement Range 5012D
5016D
5017D
5018D
5019D 0.1 to 100%
0.1 to 100%
0.1 to 100%
0.1 to 100%
0.1 to 100%
Threshold
Measurement Range
5012D
5016D
5017D
5018D
5019D 4.0 - 400 W
0.7 - 25 W
13.5 - 500 W
0.7 - 25 W
2.7 -100 W
Measurement
Uncertainty
5012D
5016D
5017D
5018D
5019D ± 2%
± 2%
± 2%
± 2%
± 2%
*Level Set Accuracy 5012D
5016D
5017D
5018D
5019D
As Peak Envelope Power
Accuracy + 2.0%
