Bird® Directional Power Sensor
5010B, 5014
PowerSensor_Directional_5010B5014-09232014
30303 Aurora Rd. Solon, OH 44139 866.695.4569 www.bird-technologies.com
DPS SPECIFICATIONS
Frequency Range Element dependent, 2 MHz to 2.7 GHz
Power Range Element dependent, 125 mW to 1 kW full
Impedance 50 Ohms
Peak/Average Ratio 10 dB maximum with DPM elements
Accuracy True Average Power , ± 5% of reading
(15 °C to 35°C), ± 7% of reading (-10 °C to
50°C), Peak Power, ±8% of full scale
Insertion VSWR 1.05:1 from 0.45 to 1000 MHz
(with N connectors)
Settling Time <2.5 seconds
Connector(s) QC Type. Female N normally supplied
Power Supply From host instrument via cable
connection
Interface(s) 5010B
5014
DB9 (Proprietary Configuration)
USB 1.1 Type B
Weight 1.12 lbs (0.51 kg)
Dimensions H x W x D
[inches (mm)]
2.3” H x 2.1” W x 3.5” D
(58 mm x 53mm x 89 mm) excluding
connectors
Directivity 30 dB typical (exact value depends on
element selected)
Humidity, Max. 95% maximum (non-condensing)
Pulse width
Parameters
>100 MHz 800 ns minimum;
26-99 MHz 1.5 μs minimum;
2-25 MHz 15 μs minimum;
Pulse Rep. Rate Peak 15 pps minimum
Pulse Duty Factor 1 x 10-4 minimum
Dynamic Range 16 dB
Operating Temp
[°C (°F)]
-10 to +50 (14° to 122°)
Storage Temp[°C (°F)] -40 to +75 (-40° to 167°)
COMPATIBLE DEVICES
5010B 5000-EX
5000-XT
SA-1700 EXP
SA-2500 EX
SA-6000 EX
SH-36S
SH-361S
SH-362
SH-362S
5014 5000-XT
VPM3
SA-3600 XT
SA-6000 XT
ACCESSORIES
5A2653-6L2 USB Locking Cable 6’
5A2653-10 USB Cable 10’
5A2264-09-MF-10 DB9 Cable 10’
Frequency
Range
2-30 MHz
25-60 MHz
50-125 MHz
100-250 MHz
200-500 MHz
400-960 MHz
950-1260 MHz
1100-1800 MHz
1700-1990 MHz
1900-2200 MHz
2200-2300 MHz
2300-2500 MHz
2500-2700 MHz
Forward
Power Range
1.25 to 50 W
12.5 to 500 W
1.25 to 50 W
12.5 to 500 W
1.25 to 50 W
12.5 to 500 W
25 to 1.0 kW
1.25 to 50 W
12.5 to 500 W
62.5 to 2.5 kW
125 mW to 5 W
1.25 to 50 W
12.5 to 500 W
125 mW to 5 W
1.25 to 50 W
2.5 to 100 W
12.5 to 500 W
25 to 1.0 kW
125 mW to 5 W
1.25 to 50 W
125 mW to 5 W
1.25 to 50 W
125 mW to 5 W
1.25 to 50 W
12.5 to 500 W
125 mW to 5 W
1.25 to 50 W
125 mW to 5 W
625 mW to 25 W
125 mW to 5 W
125 mW to 5 W
Reflected Power
Range
125 mW to 5 W
1.25 to 50 W
125 mW to 5 W
1.25 to 50 W
125 mW to 5 W
1.25 to 50 W
25 to 100 W
125 mW to 5 W
1.25 to 50 W
6.25 to 250 W
12.5 mW to 500 mW
125 mW to 5 W
1.25 to 50 W
12.5 mW to 500 mW
125 mW to 5 W
250 mW to 10 W
1.25 to 50 W
2.5 to 100 W
12.5 mW to 500 mW
125 mW to 5 mW
12.5 mW to 500 mW
125 mW to 5 W
12.5 mW to 500 mW
125 mW to 5 W
1.25 to 50 W
12.5 mW to 500 mW
125 mW to 5 W
12.5 mW to 500 mW
62.5 mW to 2.5 W
12.5 mW to 500 mW
12.5 mW to 500 mW
Forward
Element
DPM-50H
DPM-500H
DPM-50A
DPM-500A
DPM-50B
DPM-500B
DPM-1000B
DPM-50C
DPM-500C
DPM-2500C
DPM-5D
DPM-50D
DPM-500D
DPM-5E
DPM-50E
DPM-100E
DPM-500E
DPM-1000E
DPM-5J
DPM-50J
DPM-5K
DPM-50K
DPM-5L1
DPM-50L1
DPM-500L1
DPM-5L2
DPM-50L2
DPM-5M
DPM-25M
DPM-5N
DPM-5R
Reflected
Element
DPM-5H
DPM-50H
DPM-5A
DPM-50A
DPM-5B
DPM-50B
DPM-100B
DPM-5C
DPM-50C
DPM-250C
DPM-.5D
DPM-5D
DPM-50D
DPM-.5E
DPM-5E
DPM-10E
DPM-50E
DPM-100E
DPM-.5J
DPM-5J
DPM-.5K
DPM-5K
DPM-.5L1
DPM-5L1
DPM-50L1
DPM-.5L2
DPM-5L2
DPM-.5M
DPM-2.5M
DPM-.5N
DPM-.5R
ELEMENT SELECTION GUIDE
