To clear diagnostic

trouble codes, simply hold a magnet over the center of the
RDU for less than six (6) seconds.

S

Se

ellff C

Co

on

nffiig

gu

urraattiio

on

n C

Co

om

mm

maan

nd

d::

To initiate the Bendix ABS self

configure command, hold a magnet over the center of the RDU
for more than six (6) seconds, but less than 30 seconds.

Note: The RDU is specifically designed for use on vehicles equipped with
Bendix ABS. The Bendix RDU is not intended for operation and/or function
with ABS supplied by other manufacturers.

P

Pllaacce

e Y

Yo

ou

urr O

Orrd

de

err W

Wiitth

h

T

Th

he

esse

e B

Be

en

nd

diixx P

Paarrtt N

Nu

um

mb

be

errss::

• Bendix RDU Remote Diagnostic Unit – 801869
• 9-pin to 6-pin adapter cable – 801872
• 9-pin to 9-pin extension cable – 802229
• Bendix RDU plus 9-pin to 9-pin extension cable – 802436
• Bendix RDU plus 6-pin to 9-pin adapter cable – 802435

electronic controls

B E N D I X

®

R E M O T E D I A G N O S T I C U N I T ( R D U )

F

Faasstt aan

nd

d E

Eaassyy A

AB

BS

S T

Trro

ou

ub

blle

essh

ho

oo

ottiin

ng

g IIn

n aa P

Po

occkke

ett--S

Siizze

e P

Paacckkaag

ge

e

Keep your vehicles on the road and out of the shop. The portable package of remote diagnostic units from Bendix,

including the Bendix RDU and Trailer RDU offer quick, accurate diagnostics for your Bendix

®

ABS system.

Find out more. Talk to your Bendix Account Manager, call 1-800-AIR-BRAKE or visit www.bendix.com today.

Bendix Commercial Vehicle Systems • 901 Cleveland Street • Elyria, OH 44035 • 1-800-AIR-BRAKE (1-800-247-2725) • www.bendix.com
BW2482 ©2007 Bendix Commercial Vehicle Systems LLC, a member of the Knorr-Bremse Group • 11/07 • All Rights Reserved • Printed U.S.A.

VLT – Power/Communication
ECU – ABS Controller
SEN – Wheel Speed Sensor
MOD – Pressure Modulator
TRC – Traction Control
LFT – Left
RHT – Right
DRV – Drive Axle
ADD – Additional
STR – Steer Axle

A magnet over the center of the RDU is all it
takes to clear diagnostic trouble codes, or to
initiate the Bendix ABS self configure
command on the Bendix RDU.
