HARDWARE MANUAL
8
AREA48SOFT
WWW.BROTHERS-SONS.DK
SOFTWARE UPDATE
Software can be updated via DMX512 with UPLOADER from Brother, Brother & Sons ApS
and the latest software version can be found on www.brothers-sons.dk.
SPECIFICATIONS
Physical:
With barndoors
Depth:
102 mm / 4,53”
125mm / 4,93“
Width:
356 mm / 13,97”
360mm / 14,17“
Height:
275 mm / 10,82”
291,5mm / 11,47”
Weight:
2,7kg / 5,92 lbs
3,6 kg / 7,94 lbs
Data:
This product uses a 5-pin XLR for dmx input and output.
Use shielded data cables.
Do not overload the daisy chain. Up to a maximum of 32 devices can be used on a single dmx
chain.
Protocol: USITT DMX512-A
For DMX channelsheet refer to the Software manual.
Electrical:
Never connect to dimmer power
AC Power: 100 – 240 V nominal, 50/60 Hz
Powersupply: Electronic switchmode
Battery operation is optional.
Max. power consumption: 145 W.
This fixture must be connected to ground.
Thermal:
Maximum ambient temperature - t.Amb: 40° C / 104° F
Specifications subject to change without notice. For the latest specifications see
www.brothers-sons.dk
