TP10449 PAGE 4
Model No..................................................... .......... 714 Friction
Minimum Sheet Size ............................. 3 x 5" (7.6 x 12.7 cm)
Maximum Sheet Size ........................ 14 x 20" (35.5 x 50.8 cm)
Minimum Size Fold ........................................ 2 1/4" (5.7 cm)
Maximum Paper Weight .................................... 65 lb. Cover
Stack Height ........................................................ 2" (5.1 cm)
Fold Roll Speed ......................... Infinitely variable between
0"/min. and 7200"/min.
(18,288 cm/min. or 182 m/min.)
Fold Plate Depth ............................ #1 Plate, 13.5" (34.3 cm)
#2 Plate, 13.5" (34.3 cm)
Fold Roll Width .......................................... 14 1/8" (35.8 cm)
Fold Roll Diameter ......................................... 1 1/2" (3.8 cm)
Overall Physical Dimensions ................. Height 26" (66 cm)
Length 34" (88 cm)
Width 23 1/2" (60 cm)
Operating Voltage ........................ DOM. 110 VAC/1PH/60Hz
EXP. 220 VAC/1PH/60Hz
Power Consumption (folder) ................................ 250 Watts
Power Consumption (pump) .............................. 1500 Watts
Amperage (pump) ...................................... DOM. 13.6 Amp
EXP. 6.8 Amp
NOTICE
Immediately upon unpacking, carefully inspect each of the above assemblies for shipping damage. If any damage is
found, be sure to contact the delivery freight carrier to file a damage claim. Save all packaging material for the claims
adjustor to inspect.
3.0 INSTALLATION
3.1 Unpacking & Inspection
The 714 Friction is packaged in one carton, crated as
one package. It is broken down into 10 major assemblies
for shipment. These are:
A) Main Folder Assembly
B) Feed Table Assembly
C) Slitter Shaft Assembly
D) Stacker Wheel Assembly
E) Accessory Package
F) Fold Roll Guards (2)
G) Stacker Tray
H) Fold Pans (2)
I) Literature Package
J) 1/2 Pint Surewash
1.0 INTRODUCTION
Your new 714 Friction Feed Folder has been designed to give you many years of useful service provided it is
installed, maintained, and operated according to the instructions in this manual.
Your 714 Friction is a unique and versatile paper folding machine, capable of folding paper measuring between 3 x 5
inches (7.6 x 12.7 cm) and 14 x 20 inches (35.5 x 50.8 cm). The 714 Friction will make six types of folds: single fold, letter
fold, fan fold, French fold, double-parallel fold and a double letter fold, with a few simple settings. (Note: The French fold
and double-letter fold requires either two passes or the use of a right-angle unit).
Your 714 Friction is built rigid enough to ensure years of trouble-free performance, and at the same time, is compact
enough to fit on any table or desk. It is portable so it can be moved anywhere it is needed.
2.0 SPECIFICATIONS
