Baumfolder BaumCut 31.5 (For serials 700N101 thru current) - Manual (Page 18)

K1 - 10
1.0 Technical Data/Machine Layout/Transport and Installation of the Machine/Safety Relevant Machine Elements
Technical Data
Cutting width 80 cm / 31,5"
Clamp opening 10 cm / 3,93"
Feed depth 80 cm / 31,5
Power requirement (main motor):
3 phase
4,2 kW / 5,4 H.P.
Net weight 900 kg / 1983 lbs
Width 155 cm / 61"
Length 197 cm / 77,5"
Height 155 cm / 61"
Front table length 67 cm / 26,4"
Table height 90 cm / 35,4"
Clamp pressure, min. 200 daN / 440 lbs
max. 2700 daN / 5950 lbs
Knife thickness 11,75 mm / 0,4"
Grinding reserve, max . 2,5 cm / 1"
Smallest cut
without false clamp, min. 2 cm / 0,8"
with false clamp, min. 5 cm / 1,96"
Backgauge speed 0 - 13 cm/sek.
Knife speed/min . 20
Voltage supply (3 phase) 200 - 240, 50/60Hz
Fusing 3 x 20A
Attention!
The wire cross section of the main power supply according to the coun-
trys regulations.
Same regulations according the plug connectors.
Noise emission
76,5 dB (A) T with 300 cuts/hour (manual feeding)
79,5 dB (A) T with 600 cuts/hour (manual feeding)
Extraneous and room noise correction has been carried out.
daN = kp
