Baumfolder D2 Drill - Manual (Page 3)

3 TP10430
Contents
FUNDAMENTAL SAFETY ............................................................................................................... 4
INSTRUCTIONS ................................................................................................................................ 4
SECTION 1:
MAIN ASSEMBLIES ............................................................................................................... 1-1
MAIN ASSEMBLY ................................................................................................................................................ 2
SECTION 2:
DRILL BASE AND GUARD ASSEMBLIES ......................................................................... 2-1
BASE ASSEMBLY ................................................................................................................................................ 2
BASE ASSEMBLY ................................................................................................................................................ 3
MACHINE - LOWER ASSEMBLY ...................................................................................................................... 5
GUARD - FRONT ASSEMBLY ............................................................................................................................ 6
CABLE ASSEMBLY .............................................................................................................................................. 7
GUARD - TOP DOOR ASSEMBLY .................................................................................................................. 10
SECTION 3:
TABLES ..................................................................................................................................... 3-1
TABLE ASSEMBLY - MOVEABLE ....................................................................................................................... 2
TABLE ASSEMBLY ............................................................................................................................................... 4
SECTION 4:
DRILL HEAD AND HEAD ASSEMBLY ............................................................................... 4-1
DRILL HEAD ASSEMBLY ................................................................................................................................... 2
HEAD ASSEMBLY ............................................................................................................................................... 4
SECTION 5:
ELECTRICAL .......................................................................................................................... 5-1
CONTROL ASSEMBLY ........................................................................................................................................ 2
SCHEMATIC .......................................................................................................................................................... 7
SECTION 6:
HYDRAULIC ASSEMBY .........................................................................................................6-1
SECTION 7:
ACCESSORIES ........................................................................................................................ 7-1
ACCESSORIES ........................................................................................................................................................ 2
SECTION 8:
WARNING LABELS ................................................................................................................ 8-1
WARNING LABELS ............................................................................................................................................. 2
