AudioEngine A2+ POWERED DESKTOP SPEAKERS - Manual (Page 6)

A2+ setup guide 8 9
3. Connect the power cable to an AC power outlet.
4. Verify that the LED indicator on the power supply is
illuminated.
Use only the power supply provided with the speakers.
Step 3 - Connecting an Audio Source
Using the appropriate audio cable, connect the speaker inputs to
your audio source (computer, iPhone, iPad, etc.). One example is
shown in the diagram.
A2+
Computer to A2+ audio input Input
L R
Volume
USB Input
Output
Input
Computer
Headphone Output
Another option for connecting a computer to A2+ is via USB
audio. Using the included USB cable, connect as shown in the
diagram.
Computer USB port
A2+
Computer USB to A2+
�
Input
L R
Volume
USB Input
Output
Input
For PC, the A2+ should be recognized automatically.
For Mac, under System Preferences/Sound/Output, select
“Audioengine 2+”
For advanced setup tips visit: audioengineusa.com
