7. Main volume & Headphone volume
Select between the ability to adjust levels for analog outputs (21), (22) and headphone outputs (17).
The level is shown on the display (6) when adjusting, with a range of -95dB to 0dB with -1dB steps.
A click is heard as each relay engages the precision resistors. The last value is OFF which mutes
all analog outputs.
8. Display
Multi-function display can show Sample Rate, DSD Rate, Main Volume & Headphone Level, Source
Input, Headphone amplifier impedance and info concerning USB mode. See also (7), (9), (10) for
related functions.
9. Volume Select button
This allows you to select between controlling balanced outputs, unbalanced outputs and headphone
outputs. To change between balanced outputs and unbalanced outputs: press and hold the A/B
button while the balanced outputs are selected. A single illuminated dot indicates that the unbalanced
output is selected and three illuminated dots indicate that the balanced output is selected.
10. Main volume light
This indicates if balanced or un-balanced output is selected. When balanced is selected there are
3 LEDs lit and for the other output there is only one center light lit.
11. Infrared receiver
Remote control unit receiver. Do not cover!
12. Standby/Power button
Toggles standby/operation state.
13. Source button
When the display shows the sample rate, pressing this button once, briefly changes the display to
show the currently selected input source (for one second).
When the display shows an input source, pressing this button once will switch to the next available
input source.
NOTE: Only inputs fed with valid signals appear as options. Example: If only signals on AES and
TOSLINK1 inputs are present, they will be the only options available when selecting the source
(together with analog input 2).
Hint: When the display shows the sample rate, you should push this button twice in order to switch
to the next available source input.
14. Mono button
Pressing the mono button activates the summed outputs to give mono on the analog and headphone
outputs. The status of the mono function is indicated by the mono light (6). The mono feature is only
available on digital sources and via PCM playback.
15. Mute button
Press the button once for full mute. Press once again to restore normal volume. When mute is
selected either Main volume output light or Headphone output light will no longer be illuminated.
16. Headphone volume light
This indictates that Headphone volume out is being controlled by the Main volume knob. Note that
