● Re-insert the fuse holder into its position in the rear panel. Press the fuse holder gently until
it clicks into place.
The Voltikus PSU is now ready for use.
16. Voltikus Technical Specifications
Input Power
- nominal
100-120/220-240 VAC, 50 or 60 Hz
- actual 90-264 VAC, 50 or 60 Hz
Fuses 0.5A 250V Type T, 5 mm x 20 mm
Input Power Cord 3-Wire grounded / Lifted option
Terminals C14 panel mounted male connector (inlet)
Output
Voltage
18 VDC
Power (maximum) 18 W
Terminals Precision locking power connector
Safety Features:
Overload/short circuit protection Automatic power limit / short circuit protection
Input Line Protection
Fuse on both hot and neutral
Environmental
- Operating Temperature
0-50°C
Dimensions Width - 106,5 mm / 4,2 “
Height - 111,5 mm / 4,4 “
Depth - 168,0 mm / 6.6 “
Weight 2.9 kg / 6.39 lb
