AJA RD20DA Dual Channel SDI DA User Manual
Introduction
The RD20DA is a multi-standard, 2-channel, 1x4 and 1x3 SDI Distribution
Amplifier. The SDI input is re-clocked and equalized to 300 meters of cable. In
addition, the multi-standard feature allows the RD20DA to automatically adapt
to 143, 177, 270, or 360 Mb SDI inputs.
Features
RD20DA Card Module, Side View
•
2 Channel Re-Clocking, Equalizing SDI Distribution Amplifier
•
2 Separate SDI Inputs
•
1x3, 1x4 SDI Outputs
•
Multi-Standard: 143/177/270/360 Mb
Block Diagram
