AJA D5D NTSC/PAL To Serial Decoder User Manual — Installation
Switch 3—Configure Pedestal For Composite/Sync BNC
:
Switch 4—Configure Comb Filter
:
Input Selection
Matrix (2 BNCs)
The following table shows the combinations of DIP switch settings required to configure the
two input BNCs. Outputs are always Serial Digital.
Installation
Typically, D5D installation consists of the following:
1.
disconnect +5VDC from the convertor
2.
configure the DIP switch for the desired equipment configuration and video formats
3.
connect video equipment to the convertor BNCs
4.
apply +5VDC power to the converter (AJA power supply model DWP)
ON
OFF
7.5 IRE pedestal for NTSC
No pedestal (for inputs without Pedestal)
ON
OFF
Selects a three line adaptive comb filter (one
line plus a 1.5us delay)
Selects a two line non-adaptive comb filter (1.5 us
delay)
Output Format
DIP Switch
#1
DIP Switch
#3
Y and C inputs selected (Pedestal)
Y/C ON
ON
Composite inputs (no pedestal)
Y/C OFF
OFF
