Switch 5 Embedded
Channel Mapping

The following table shows how switch 5 affects embedded channel mapping.

Table 2. DIP SW 5 Embedded Channel Mapping

DIP SW 5

EMBD GRP

AES Input
Channel

SDI
Embedded
Group

SDI Embedded
Output
Channel

Left (1/2)

1 —>

1

1

2 —>

2

3 —>

3

4 —>

4

5 —>

2

5

6 —>

6

7 —>

7

8 —>

8

Right (3/4)

1 —>

3

9

2 —>

10

3 —>

11

4 —>

12

5 —>

4

13

6 —>

14

7 —>

15

8 —>

16
