HD10MD3 Mini-Converter v1.0r2 www.aja.com 9
1
2
3
6
5
4
Jumper
J8
Table 3. HD10MD3 Jumper Setting Descriptions
Jumper Function Jumper OFF (default) Jumper ON
Between
Pins 1
and 2 3:2
Pulldown
synchroniza
tion RP188 is used to synchronize
3:2 pulldown sequence. RP215 is used to synchronize
3:2 pulldown sequence.
NOTE: In both cases the “A Frame” is synchronized to frame with timecode
“xx:00”.
Between
Pins 5
and 6 Vertical
blanking
and sync Output start of vertical sync
lines up with input start of
vertical sync (per RP168). Output start of vertical
blanking lines up with input
start of vertical blanking.
