Simplified Block Diagram

I/O Connections

HD RGB or YPbPr Outputs

(selected by DIP switch)

HD-SDI

Input

De-serializer

Cable EQ

Y G

Pb B

H Drive

V Drive

(Output is selected by DIP switch)

Pr R

DA Outputs

D/A

Conversion

HD-SDI Out 1

HD-SDI Out 2

HD-SDI Input

HD-SDI Loop

Output

Configuration

Determined by
DIP switch on
other side of

Converter

Output 1

BNC

Connects to Converter

Output Connector for
HD-RGB or YPbPr Video

Connects to Converter
Output Connector for
VGA Video

BNCs for HD-RGB
or YPbPr equipment

HD10C2 Component Video Cable and HD15 SVGA Adapter

HD-SDI Loop

Output 2

+ 5 VDC

Power

Input

D-Connector
