MiniConfig Settings
Summary
MiniConfig settings for various input analog formats are shown in Table 1
Table 2. Input Analog Formats, DIP Switch Settings, and SDI Output Formats
MiniConfig Controls Notes
Input
Standard
Input Analog Format Format Color Space Pedestal
525i59.94 Composite NTSC Composite X On
NTSC S-Video S-Video X On
Composite NTSC-J Composite X Off
NTSC-J S-Video S-Video X Off
Component YPbPr SMPTE/EBU-N10 Component YPbPr
(SMPTE) X
Component YPbPr Betacam Component YPbPr
(Betacam) On
Component YPbPr Betacam-J Component YPbPr
(Betacam) Off only selectable via
MiniConfig
625i50 Composite PAL + S-Video Composite X X
PAL S-Video S-Video X X
Component YPbPr SMPTE/EBU-N10 Component X X
720p * Component YPbPr SMPTE/EBU-N10 X YPbPr
(SMPTE) X
Component RGB X RGB X
1080i/psf * Component YPbPr SMPTE/EBU-N10 X YPbPr
(SMPTE) X
Component RGB X RGB X
* = all supported frame rates Note: X = don't care
