MiniConfig Settings
Summary
SDI input formats and the MiniConfig settings for various analog output formats are
shown in
Table 2
Table 3. SDI Inputs, MiniConfig Settings, and Analog Output Formats
MiniConfig Controls Notes
Input SDI Std Output Analog Format Format Color Space Pedestal
525i 59.94 Composite NTSC + S-Video Composite X On Composite and S-Video are
output simultaneously
525i 59.94 Composite NTSC-J + S-Video Composite X Off Composite and S-Video are
output simultaneously
525i 59.94 Component YPbPr SMPTE/
EBU-N10 Component YPbPr (SMPTE) X
525i 59.94 Component YPbPr Betacam Component YPbPr
(Betacam)
On
525i 59.94 Component YPbPr Betacam-J Component YPbPr
(Betacam)
Off Only selectable via MiniConfig
625i 50 Composite PAL + S-Video Composite X X Composite and S-Video are
output simultaneously
625i 50 Component YPbPr SMPTE/
EBU-N10 Component YPbPr (SMPTE) X
720p * Component YPbPr SMPTE/
EBU-N10 X YPbPr (SMPTE) X
720p * Component RGB X RGB X
1080i/p/psf * Component YPbPr SMPTE/
EBU-N10 X YPbPr (SMPTE) X
1080i/p/psf * Component RGB X RGB X
* = all supported frame rates Note: X = don't care
