HD10A-Plus v1.0r1 www.aja.com 8
Specifications
Formats • 525i/625i, 1080i 50/59.94/60 Hz
• 1080psf 23.98/24/25/29.97/30 Hz
• 720p 50/59.94/60 Hz
Inputs • HD component YPbPr, RGB (SMPTE-274, 296), BNC
• SD component (Betacam, SMPTE/EBU-N10)/composite/YC (S-Video), BNC
• External RGB Sync
Outputs HD/SD-SDI, SMPTE-259/292, 3 x BNC
Frequency Response • Y +0, -.5 dB to 30 MHz
• C +/- .25 dB to 15 MHz
User Controls External DIP switch
• Component/Composite (SD Only)
• S-Video (off/on) (SD Only)
• Pedestal Present (on/off) (SD Only)
• Format (YPbPr/RGB) (HD Only)
• NTSC-J (off/on) (SD 525i Only)
• SYNC (INT/EXT)
Physical 5.8” x 3.1” x 1” (147 x 79 x 25 mm)
Power +5-20 VDC, 4 watts
