HA5-Plus Mini-Converter v1.3 www.aja.com 16
Appendix A: Specifications
Video
Video Input HDMI
Input Formats: • 525i, 525p
• 625i, 625p
• 720p 50/59.94/60
• 1080i 50/59.94/60
• 1080p23.98/24/25/29.97/30/50/59.94/60
• 2K 1080p23.98/24/25/29.97/30/50/59.94/60
Video Output SDI - 3G/HD/SD-SDI, SMPTE-259/292/296/424/425, 1 x BNC
Output Formats: • 525i 29.97
• 625i 25
• 720p 50, 59.94, 60
• 1080i 25, 29.97, 30
• 1080p 23.98, 24, 25, 29.97, 30
• 1080PsF 23.98, 24, 25, 29.97, 30
• 1080p 50, 59.94, 60 - SMPTE 425-1 Level A/Level B Mapping structure 1
(1920X1080 4:2:2 10-bit YCbCr)
• 2K 1080p23.98/24/25/29.97/30/50/59.94/60
(2048X1080 4:2:2 10-bit YCbCr)
HDCP Content not supported
Audio
HDMI Audio Input Eight channels (4 pairs) of embedded audio supported
Rates supported: • 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, and 96 kHz
Analog Audio Input Unbalanced, -10 db, 2 x RCA
SDI Audio Output Eight channels (4 pairs) of embedded audio (24-bit/48 KHz)
Embed to either SDI audio Ch 1-8 or Ch 9-12
Physical
Size 4.6" x 2.4" x 1" (117 x 61 x 25 mm)
Power Uses AJA Power Supply model DWP-U-R1 (included)
100-240V, 50/60Hz Universal Input
+5-20V DC, 3 Watts
