100600
3513−11 Assemblies include all parts shown in frames. 05/23/2007
11
670 793485 Spacer−Fuel Tank
Used on Type No(s).
0015, 0025, 0100,
0110, 0111, 0112,
0115, 0116, 0118,
0119, 0120, 0121,
0122, 0123, 0124,
0126, 0771.
718 690959 Pin−Locating
(Cylinder)
741 793446 Gear−Timing
742 93941 Retainer−E Ring
Used on Type No(s).
0116, 0120.
745 793491 Screw
(Brake)
(M5x25.3mm Long)
Used on Type No(s).
0015, 0025, 0100,
0110, 0111, 0112,
0115, 0116, 0118,
0119, 0120, 0121,
0122, 0123, 0124,
0126, 0771.
783 691918 Gear−Pinion
Used on Type No(s).
0116, 0120.
783A 691269 Gear−Pinion
Used on Type No(s).
0116, 0120.
787 793513 Arm−Lever
793 793511 Screw/Nut Set
(Lever Arm)
832 793499 Guard−Muffler
Used on Type No(s).
0110, 0111, 0119,
0122, 0123, 0124,
0126, 0771.
832A 793681 Guard−Muffler
Used on Type No(s).
0112, 0115, 0116,
0118, 0120.
836 793500 Screw
(Muffler Guard)
(M5x12.3mm Long)
Used on Type No(s).
0110, 0111, 0112,
0115, 0116, 0118,
0119, 0120, 0122
0123, 0124, 0126,
0771.
843 691884 Sleeve−Lever
Used on Type No(s).
0015, 0025, 0100,
0121, 0122.
847 793474 Diptstick/Tube
Assembly
Used on Type No(s).
0015, 0025, 0100,
0110, 0111, 0112,
0115, 0116, 0118,
0119, 0120, 0121,
0122, 0123, 0124,
0126, 0771.
851 493880S Terminal−Spark Plug
857 793533 Trim−Blower Housing
Cover
Used on Type No(s).
0111, 0112, 0115,
0116, 0119, 0120,
0123, 0124, 0126,
0771.
868 793507 Seal−Valve
875 793462 Base−Air Cleaner
Used on Type No(s).
0100.
875A 793492 Base−Air Cleaner
Used on Type No(s).
0015, 0025, 0110,
0111, 0112, 0115,
0118, 0116, 0119,
0120, 0121, 0122,
0123, 0124, 0126,
0771.
883 793497 Gasket−Exhaust
Used on Type No(s).
0015, 0025, 0100,
0110, 0111, 0112,
0115, 0116, 0118,
0119, 0120, 0121,
0122, 0123, 0124,
0126, 0771.
910 794101 Stud
(Alternator)
Used on Type No(s).
0116, 0120.
914 699480 Screw
(Rocker Cover)
(15.8mm)
921 793531 Cover−Blower Housing
Used on Type No(s).
0111, 0112, 0115,
0116, 0119, 0120,
0123, 0124, 0126,
0771.
922 692135 Spring−Brake
Used on Type No(s).
0015, 0025, 0100,
0110, 0111, 0112,
0115, 0116, 0119,
0120, 0121, 0122,
0123, 0124, 0771.
923 793490 Brake
Used on Type No(s).
0015, 0025 0100,
0110, 0111, 0112,
0115, 0119, 0120,
0121, 0122, 0123,
0124, 0126, 0771.
923A 794107 Brake
Used on Type No(s).
0116, 0120.
925 793678 Cover−Linkage
Used on Type No(s).
0118.
937 494146 Spline−Starter
Used on Type No(s).
0116, 0120.
942 793673 Bracket−Brake
Used on Type No(s).
0015, 0025.
955 793465 Plug−Carburetor
Used on Type No(s).
0015, 0025, 0100,
0110, 0111, 0112,
0115, 0116, 0118,
0119, 0120, 0121,
0122, 0123, 0124,
0771.
957 692046 Cap−Fuel Tank
(Black)
Used on Type No(s).
0100, 0110, 0111,
0112, 0115, 0116,
0118, 0119, 0120,
0122, 0123, 0124,
0126, 0771.
957A 793606 Cap−Fuel Tank
(Black/Grey)
Used on Type No(s).
0015, 0025 0121.
K Engine Gasket Set−Reference 358 D Carburetor Overhaul Kit−Reference 121
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
