100600
3513−10 Assemblies include all parts shown in frames. 05/23/2007
10
332 690662 Nut
(Flywheel)
(SAE)
(.625−18 I.D.)
332A 792723 Nut
(Flywheel)
(Metric)
(M16x1.5mm I.D.)
333 793449 Armature−Magneto
334 793454 Screw
(Magneto Armature)
337 692051 Plug−Spark
Used on Type No(s).
0015, 0100, 0121.
−−−−−−− Note −−−−−
692720 Plug−Spark
Used on Type No(s).
0025, 0110, 0111,
0112, 0115, 0116,
0118, 0119, 0120,
0122, 0123, 0124,
0126, 0771.
356 692390 Wire−Stop
Used on Type No(s).
0100, 0110, 0111,
0112, 0115, 0116,
0118, 0119, 0120,
0121, 0122, 0123,
0124, 0126, 0771.
358 793623 Gasket Set−Engine
363 19069 Puller−Flywheel
365 793458 Screw
(Carburetor)
(27.0mm)
371 794574 Gear−Cam
383 19374S Wrench−Spark Plug
404 690272 Washer
(Governor Crank)
425 793460 Screw
(Air Cleaner Cover)
(36.2mm)
445 792038 Filter−Air Cleaner
Cartridge
474 794103 Alternator
Used on Type No(s).
0116 0120.
505 793515 Nut
(Governor
Control Lever)
513 692358 Clutch−Drive
Used on Type No(s).
0116, 0120.
523 793475 Dipstick
Used on Type No(s).
0015, 0025, 0100,
0110, 0111, 0112,
0115, 0116, 0118,
0119, 0120, 0121,
0122, 0123, 0124,
0126, 0771.
524 793476 Seal−Dipstick Tube
Used on Type No(s).
0015, 0025, 0100,
0110, 0111, 0112,
0115, 0116, 0118,
0119, 0120, 0121,
0122, 0123, 0124,
0126, 0771.
525 793477 Tube−Dipstick
Used on Type No(s).
0015, 0025, 0100,
0110, 0111, 0112,
0115, 0116, 0118,
0119, 0120, 0121,
0122, 0123, 0124,
0126, 0771.
535 793676 Filter−
Air Cleaner Foam
Used on Type No(s).
0015, 0025, 0771.
562 793514 Bolt
(Governor
Control Lever)
578 398153 Wire Assembly
Used on Type No(s).
0015, 0025.
578A 794104 Wire Assembly
Used on Type No(s).
0116, 0120.
592 793481 Nut
(Rewind Starter)
601 791850 Hose−Clamp
Used on Type No(s).
0015, 0025, 0100,
0110, 0111, 0112,
0115, 0116, 0118,
0119, 0120, 0121,
0122, 0123, 0124,
0126, 0771.
608 793470 Starter−Rewind
Used on Type No(s).
0015, 0025, 0100,
0110, 0111, 0112,
0115, 0116, 0118,
0119, 0120, 0121,
0122, 0123, 0124,
0126, 0771.
613 793469 Screw
(Muffler)
Used on Type No(s).
0100.
−−−−−−− Note −−−−−
793495 Screw
(Muffler)
Used on Type No(s).
0015, 0025, 0110,
0111, 0119, 0121,
0122, 0123, 0124,
0126, 0771.
793680 Screw
(Muffler)
Used on Type No(s).
0112, 0115, 0116,
0118, 0120.
615 690340 Retainer−Governor
Shaft
616 793448 Crank−Governor
621 692310 Switch−Stop
Used on Type No(s).
0015, 0025, 0100,
0110, 0111, 0112,
0115, 0116, 0118,
0119, 0120, 0121,
0122, 0123, 0124,
0771.
623 793628 Seal−O Ring
(Carburetor Spacer)
635 66538S Boot−Spark Plug
662 793478 Stud
(Rewind Starter)
(M5x32.9mm Long)
Used on Type No(s).
0015, 0025, 0100,
0110, 0111, 0112,
0115, 0116, 0118,
0119, 0120, 0121,
0122, 0123, 0124,
0126, 0771.
662A 793479 Stud
(Rewind Starter)
(M5x49.6mm Long)
Used on Type No(s).
0015, 0025, 0100,
0110, 0111, 0112,
0115, 0116, 0118,
0119, 0120, 0121,
0122, 0123, 0124,
0162, 0771.
K Engine Gasket Set−Reference 358 D Carburetor Overhaul Kit−Reference 121
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
