3.7 35 Outlaw ®
S
eCtiOn
3 • u
Sing
y
Our
B
Oat
b. p
oWer
s
TeerinG
The steering system is an enclosed push-pull cable
that is hydraulically assisted (power steering) at the
stern drive end (fig. 3.7.1). ThE CaBlE anD ITs
COnnECTIOns TO ThE sTEERIng WhEEl anD
TO ThE OUT DRIVE MUsT BE InsPECTED aT
lEasT TWICE a yEaR By yOUR BaJa DEalER.
see section 8 of this manual for inspection, service
and maintenance recommendations.
The power steering pump fluid level MUST be
checked every time prior to using the boat. Refer
to the steering system information in your Owner’s
Packet.
p
Ower
S
teering
S
ySteM
(F
ig
3.7.1)
POWER sTEERIng
CylInDER
sTEERIng CaBlE flUID
RETURn lInE
flUID
PREssURE
lInE
flUID
RETURn
lInE
sTEERIng WhEEl
ChECk & aDD
flUID hERE
hElM
sTEERIng ROTOR
