2 • g, Ection, Eneral – Baja Marine Outlaw 35 User Manual
Page 31: Rrangement, S.a.e.)
35 Outlaw
®
2.2
S
eCtiOn
2 • g
eneral
B
Oat
a
rrangeMent
3. b
asic
b
oaT
D
iMensions
anD
c
learances
(u
niTeD
s
TaTes
s
TanDarD
s.a.e.)
35 O
utlaw
s
pecificaTions
Overall length ....................................................................35'
Overall length (w/ drive down)........................................36'6"
Overall length w/ swim Platform ....................................37'1"
Beam (width) .....................................................................8'6"
Draft (stern drive down) ..................................................... 40"
Draft (stern drive up in trailering position)...........................25"
Dry Weight .........................................................8,100 pounds
fuel Capacity........................................................ 185 gallons
h
eiGhT
D
iMensions
from keel
without Windshield.............................................................72"
keel To Top
Of Windshield.....................................................................78"
from Waterline
without Windshield..............................................................52"
from Waterline to
Top of Windshield................................................................58"
8’ 6”
Beam
(fIg. 2.2.3)
Specification measurements are approximate
and subject to variance.
S
tern
d
rive
(i
nBOard
-O
utBOard
) e
ngine
(F
ig
2.2.2)
sTERn DRIVE UnIT
(lOWER UnIT)
DRafT
(stern Drive Down)
40"/102cm
WaTER lInE
hUll
(TRansOM)
EngInE
B
Oat
d
iMenSiOnS
and
C
learanCeS
(F
ig
. 2.2.1)
35"
72"
78"
