Bernard Q-Gun ™ Series - Manual

Centerfire TM contact tips, nozzles and diffusers
are easy-to-use and high performing - they
provide better arc starts, less spatter and more
consistent welds - and also last up to three times
longer than competitive brands.
Necks available in fixed, rotatable and multiple
length options for optimal weld accessibility and
improved operator comfort. Rotatable necks
changeover without tools.
Patented Jump Liner allows quick neck change
and replacement of only most commonly worn or
clogged liner area, which reduces the amount of
time a gun is offline and minimizes inventory.
Liners coiled in-house with proprietary process
that improves wire feed performance and 100
percent tested to ensure smoothest wire feed in
the industry.
Handle is comfortable to reduce user fatigue and
ventilated to reduce heat.
Back end with durable rigid strain relief and
easily interchangeable direct plugs and trigger
leads connect to wire feeders and machines
from major manufacturers and allow simple
maintenance.
Q150 MIG Q-Gun TM shown with
curved handle, medium 45˚
rotating neck.
All Guns are Not Created Equal.
A MIG gun should be durable, easy to
use and customized to your specific
application. Our MIG guns put you in
control: you choose the options you need
and we'll build a gun to last. We even
ship most of our guns within 24 hours.
Issued Nov. 2006 • Index No. SPEC Q150-1.3
Q-Gun
™
Series
150 Amp MIG Guns
USA
Made with
Pride and without
Compromise in the
Lightweight, comfortable and
easy-to-use. Our Q150 MIG gun
is a perfect fit for low amperage
industrial applications.
Phone: 800-946-2281 (US Only) 708-946-2281 (Outside US)
Fax: 708-946-6726
For more information, visit us at BernardWelds.com
Q150 Amperage Ratings
Duty Cycle Description
100% NEMA 100%CE 60% CE 35%CE
160 150 180 225 CO
2
Gas
n/a 140 150 180 80%AR20%CO
2
Bernard ®
An Illinois Tool Works Company
449 West Corning Road, Box 667
Beecher, Illinois 60401 USA
