Bryan U-Tube
Heat Exchangers

Heat Exchanger Type
Pool Heater

Indirect Tank Heater

U-tube tank heaters are mounted in a new Bryan tank

or supplied for mounting in an existing tank.

A Reputation
for Quality

Bryan continues to combine the advan-
tages of past experience with advanced
technology, moving into the future as the
leader in design, manufacture and appli-
cation of accessory equipment to opti-
mize performance and enhance longevity
of your boilers.

All of the features and quality of the time proven Bryan
“Indirect Heaters” are now available using an existing
central boiler heating plant as the heat source. Hot
water or steam is taken from the heating main and cir-
culated thru the Exchanger shell. The pool water is
heated as it passes through the copper “Indirect” coil.

This installation diagram
shows a typical application
of the tank heater installed
in the tank. Horizontal or
vertical tanks are available
with tank heater factory
installed.

Water to
Water

Bryan’s U-tube heat exchangers are built to offer long life
and maximum performance in all applications, including
service water, space heating, radiation, swimming pool
heating and various process applications.

These instantaneous heaters operate with steam or

water on the shellside and water on the tubeside. Bryan
offers U-tube heat exchangers in sizes ranging from 4"
diameter to 12" diameter and lengths up to 10', in both
two and four pass designs.

Model UW-6-2-2

Model SH-16-32-PW

Model US-8-5-2

Model UT-10-10-2

Steam to
Water
