Operating features – Wood’s Powr-Grip MTA6LP6FAIR User Manual
Page 5
Rev 10.8/2-13
3
MTA4/6LP6FAIR: #35099
OPERATING FEATURES
Note: Components featured in the following instructions for assembling, operating or
maintaining the vacuum lifter are underlined on their first appearance in each section.
Standard MTA6LP6FAIR shown.
1 VACUUM RELEASE BUTTON
5 AIR PRESSURE REGULATOR
10 VACUUM PAD
2 CONTROL HANDLE
6 VACUUM PUMP (VENTURI)
11 PAD ARM RELEASE
3 LIFT BAR
7 AIR FILTERS
12 PAD ARM LIMIT DISK
4 VACUUM GAUGE
8 LIFT SPOOL
13 AIR SUPPLY VALVE
9 PAD FRAME
