Operating features – Wood’s Powr-Grip MRPT89AC User Manual
Page 7
Rev 30.0/6-13
5
MRPT-AC: #35060
OPERATING FEATURES
Note: Components featured in the following instructions for assembling, operating or
maintaining the vacuum lifter are underlined on their first appearance in each section.
Standard MRPT89AC shown.
1 LIFT BAR
6 PAD FRAME
12 VACUUM RELEASE BUTTON
2 LIFT BAIL
7 VACUUM GAUGE
13 AIR FILTER
3 VACUUM PAD
8 VACUUM LIFT LIGHT
14 TILT ACTUATOR
4 POWER SWITCH
9 VACUUM RESERVE TANK
15 Enclosure with VACUUM SWITCH
5 VACUUM PUMP
10 TILT TOGGLE SWITCH
16 CONTROL HANDLE
11 ROTATION RELEASE LEVER
